Orange Pi Touch Screen (For Orange Pi 3G-IoT)
Per piece
Product Descriptions:
Orange Pi Touch Screen for the Orange Pi 3G-IoT, consider factors like display size, resolution, touch technology, and compatibility with the board's interfaces. Review the product specifications and compatibility details provided by the touch screen manufacturer to ensure proper connectivity and functionality with the Orange Pi 3G-IoT.
Product Parameters:
| Touch Panel Parameter | Touch panel mode | Capacitive screen |
| Size | 68.40 mm *141.32 mm | |
| Driver IC | GSL2338 G+F | |
| Power voltage | 2.8V | |
| Light transmission | ≥82% | |
| Surface hardness | 7H | |
| Operating temperature | -10℃~+60℃≤90%RH | |
| Storage temperature | -20℃~+70℃≤90%RH | |
| Display panel parameter | Display mode | TFT |
| Driver IC Whether contains with RAM |
ST7701 | |
| Pixel lattice | 480（RGB）X 854 | |
| Module size | 66.4mm*120.05mm*2.06mm | |
| Display area | 62.06 mm *110.42 mm | |
| Connector | MIPI | |
| LED no. | 12-LEDn | |
| Connect method | Series parallel | |
| Current | 40MA |
