Nano/NX Carrier Board for GPU Cluster and Server

• Jetson Mate is a carrier board in which you can install up to 4 NVIDIA Jetson Nano/NX SoMs. There is an onboard 5-port Gigabit switch enabling the 4 SoMs to communicate with each other. All the 3 peripheral SoMs can be powered on or off separately. With a 65W 2-Port PD charger, for Jetson Nano SoMs or a 90W 2-Port PD charger for Jetson NX SoMs, and one ethernet cable, developers can easily build their own Jetson Cluster.

Product Specifications:

Product Name	Carrier Board for GPU Cluster and Server
Brand	Seeed Studio
Color	Black
Use	GPU Cluster and Server
Card Slots	4 Slots
Onboard 5-Port Gigabit Switch	Microchip KSZ9896CTXC
Power	65W PD for Jetson Nano SoMs 90W PD for Jetson NX SoMs
Dimensions	110mm x 110mm
Shipment Weight	0.4 kg
Shipment Dimensions	10 × 8 × 6 cm

Product Features:

1. Easy to build a GPU cluster with easy-to-follow guides provided.
2. Can install up to 4 NVIDIA Jetson Nano/NX SoMs.
3. Onboard 5-port Gigabit switch for the SoMs to communicate with each other.
4. One master node with 3 worker nodes with the ability to power on/off the worker nodes separately.

Applications:

• GPU Server
• Home lab
• GPU Cluster

Packages Includes:

• 1 x Jetson Mate
• 1 x Cable: 30mm Long Black 4-Pin Male to 4-Pin Female 28 AGW – 1.25mm
